100% Eco
Up to 100% Saving in day time
-
Grid AC Power Limiter
Limit AC power from 0-300W
-
Savings
No Inverter battery, or Charger controller needed
-
Wide Operating Temperature
Temperature Range between: -10 to +60°C
-
Max Efficiency
DC-driven
-
Auto Balance
AC/DC auto balance
| Items | Unit | 12000BTU | 18000BTU | 24000BTU |
| Mode | / | JPRA-12KCH-G1 | JPRA-18KCH-G1 | JPRA-24KCH-G1 |
| Power DC, PV, Series Connection | VOC(V) | 80~380 | 80~380 | 150~410 |
| ISC(A) | </=14A | </=14A | </=20A | |
| Grid Power Voltage | VHz | 208V~240V/50~60Hz | 208V~240V/50~60Hz | 208V~240V/50~60Hz |
| Cooling Capacity(T1) | BTU | 12000(3000-13300) | 17500(4100-18500) | 22000(6100-27000) |
| Cooling Power Input(T1) | W | 940(190-1270) | 1510(220-1950) | 1790(300~3200) |
| Heating Capacity | W | 3600(900-3960) | 5150(1500~5300) | 7000(1800-7200) |
| Heating Power Input | W | 940(180~1250) | 1400(220~1450) | 2030(340~2150) |
| EER | BTUN | 12.66 | 11.50 | 12.19 |
| Indoor Unit Dimension(WxHxD) | mm | 850×298×200 | 910x298×230 | 1030×320×240 |
| Indoor Unit Packing(WxHxD) | mm | 875×360×270 | 970x370x250 | 1110×405×315 |
| Outdoor Unit Dimension (WxHxD) | mm | 760×552×256 | 823x635x310 | 890x700x320 |
| Outdoor Unit Packing(WxHxD) | mm | 850×590×350 | 995x675x445 | 1045x760x445 |
| Items | Unit | 12000BTU | 18000BTU | 24000BTU |
| Mode | / | JPRB-12KCH-G1 | JPRB-18KCH-G1 | JPRB-24KCH-G1 |
| Power DC, PV, Series Connection | VOC(V) | 80~380 | 80~380 | 150~410 |
| ISC(A) | </=14A | </=14A | </=20A | |
| Grid Power Voltage | VHz | 208V~240V/50~60Hz | 208V~240V/50~60Hz | 208V~240V/50~60Hz |
| Cooling Capacity | W | 3500(800~3900) | 5150(1200~5600) | 6400(1800~7800) |
| Cooling Power Input | W | 920(140~1150) | 1430(220~2000) | 1690(340~2550) |
| Heating Capacity | W | 4000(900~4400) | 5150(1200~5300) | 7030(1800~7800) |
| Heating Power Input | W | 1020(150~1350) | 1340(220~1450) | 1780(320~2190) |
| EER | WN | 3.75 | 3.55 | 3.75 |
| Indoor Unit Dimension(WxHxD) | mm | 850×298×200 | 910x298×230 | 1030×320×240 |
| Indoor Unit Packing(WxHxD) | mm | 875×360×270 | 970x370x250 | 1110×405×315 |
| Outdoor Unit Dimension (WxHxD) | mm | 760×552×256 | 823x635x310 | 890x700x320 |
| Outdoor Unit Packing(WxHxD) | mm | 850×590×350 | 995x675x445 | 1045x760x445 |
