| Technical Data |
HLM8A-D1 |
HLM10A-D1 |
HLM12A-D1 |
HLM15A-D1 |
| Rated Power |
8000VA/8000W |
10000VA/10000W |
12000VA/12000W |
15000VA/15000W |
| PV input data |
| Max PV Input Power(W) |
16000 |
20000 |
24000 |
30000 |
| Max.PV Input Voltage(V) |
1000 |
| Start-up Voltage(V) |
150 |
| MPPT Voltage Range(V) |
200~800 |
| Max.Current per MPPT(A) |
18/18 |
36/18 |
36/20 |
| Max.Short-circuit current MPPT(A) |
22.5/22.5 |
45/22.5 |
45/25 |
| Number of MPP Trackers |
2 |
| AC Output Data(On-Grid) |
| Rated AC Output Power(W) |
8800 |
11000 |
13200 |
16500 |
| Rated voltage(V) |
380/400V |
| Rated Frequency(Hz) |
50/60Hz |
| Max Output Curent(A) |
13.3 |
16.7 |
20 |
24 |
| Output power factor |
1(-0.8 leading~+0.8 lagging) |
| Battery Input Data |
| Battery Type |
Lithium, Lead-acid |
| Battery Voltage Range(V) |
48 |
| Max.Charging Current(A) |
190 |
210 |
250 |
280 |
| AC Output Data(Off-Grid) |
| Max.Input Power(W) |
8000 |
10000 |
12000 |
15000 |
| Maximum output apparent power |
>200%,15sec |
| Rated voltage(V) |
380/400V |
| Rated Frequency(Hz) |
50/60Hz |
| Max.Input Current(A) |
13.3 |
16.7 |
20 |
22.8 |
| Efficiency |
| Max efficiency |
98.00% |
| Europe efficiency |
94.50% |
| MPPT efficiency |
97.50% |
| Protection |
| PV input reverse polarity protection |
Yes |
| PV insulation resistance detection |
Yes |
| Residual current detection |
Yes |
| Output over current protection |
Yes |
| Output short circuit protection |
Yes |
| Output over-voltage protection |
Yes |
| Basic Data |
| Operating Temperature Range |
-25°℃~60°℃(frequency-decreasing above 45℃) |
| Storage temperature |
-30~65℃ |
| Relative Humidity |
0%～95% |
| Working altitude |
≤4000m(frequency-decreasing above 2000m) |
| Cooling |
Intelligent forced air cooling |
| Noise (dB) |
<55 |
| Weight(kg) |
38 |
43 |
| Dimensions(W*H*Dmm) |
475*683*256 |
750*475*256 |
| Protection Degree |
IP66 |
| Communication Interfaces |
RS485/CAN/WiFi |
| Safety/EMC Standard |
NB/T32004-2018,IEC62109,IEC61000,IS16169&IS16221(BIS) |
| Grid-connected standard |
IEC61727,EN50549-1,VDE-4105,NRS-097-2-1,OVE-Richtlinie R25,UNE217001/2,Ordinace No.140 |
| Other standard |
IEC61683.IEC62116,EN50530,IEC60068 |
English
中文简体
IP66 High level protection
LCD Color Screen Operation
Dual back up output
AC couple to retrofit existing solar system
Single PV Operation Supported
UPS switch over time < 10ms
Wi-Fi Standard
Max. charging/discharging current of 250A
Support up to 12 unit in parallel
Multiple Battery Compatibility: Works with various battery technologies, including lithium-ion and lead-acid
