IP21 Protection Dlesign for Anti-Dust and Waterproof -
LCD Color Screen Operation -
Dual back up output -
Wi-Fi Smart Monitoring Platform -
Single PV Operation Supported -
Max.efficiency>95% -
Support dry contact starting generator(Optional) -
The maximum current of a single string module is 20A -
Support up to 9 unit in parallel(Optional) -
Support dry contact starting generator(Optional)
-
Supports three-phase output after single-phase parallel operation -
Power supply can be switched automatically and switching time within 10ms
| Technical Data | ODS5K-S1-F | OTS6K-S1-F |
| Rated Power | 5000VA/5000W | 6000VA/6000W |
| PV input data | ||
| Max.PV Input Power(W) | 9000 | 9000 |
| Max.PV Input Voltage(V) | 500 | |
| MPPT Voltage Range(V) | 60-450 | |
| Max.Current per MPPT(A) | 27 | 27 |
| Number of MPP Trackers | 1 | 1 |
| AC Output Data | ||
| Rated AC Output Power (W) | 5000 | 6000 |
| Rated Output Current(A) | 21.73 | 26.08 |
| Peak Output Power, Time | 60S@102%-125% Load; 10S@>125%Load |
60S@102%-120% Load; 10S@>120%Load |
| Rated voltage | 220/230/240VAC | |
| Rated Frequency | 50/60Hz | |
| Switch Time(ms) | 10mS(@UPS) | |
| Output Voltage Waveform | Pure Sine Wave | |
| Max Efficiency | 98.00% | |
| AC input Data | ||
| Rated voltage | 220/230/240V 220/230/240VAC |
|
| Voltage range(V) | 90-280VAC±3V(Normal mode)170-280VAC±3V(UPS mode) | |
| Input Type | L+N+PE | |
| Rated Frequency | 50/60Hz | |
| Feed in grid Current(A) | 21.73 | 26.08 |
| Battery input data | ||
| Battery Type | Lithium, Lead-acid | |
| Battery Voltage (V) | 24 | 48 |
| Max.Charging Current(A) | 160 | 120 |
| Float Charging Voltage(V) | 27 | 54 |
| Protection | ||
| Integrated | Over Current Protection/Over and under Voltage Protection//Output Short Circuit Protection/Over-temperature protection/Over and under Frequency Protection/Surge Protection |
|
| General Data | ||
| Display | LCD | |
| Operating Temperature Range |
-10～60℃ | |
| Dimension(WxHxD) (mm) |
410*336*110 | 410*336*110 |
| Weight(kg) | 9.5 | 10 |
| Installation method | Wall-mounted | |
| Relative Humidity | 5%～95%(Non-condensing) | |
| Max.Operating Altitude(m) | Derating over 1000m, Max 4000m, Refer to IEC62040 | |
| Protection Degree | IP21 | |
| Communication | RS485/CAN/RS232 | |
| Number of parallel | / | 9 |
| Standard | IEC61683,IEC61000,IEC 62109-1/2 | |
