| Product Model |
HLS3A-D1 |
HLS3.6A-D1 |
HLS5A-D1 |
HLS6A-D1 |
HLS8-G1 |
HLS10-G1 |
| Battery Input Parameters |
| Battery Type |
Lithium or Lead-acid Battery |
| Battery Voltage Range (V) |
40-60 |
| Max.Charge Current (A) |
70 |
90 |
120 |
125 |
190 |
210 |
| Max.Discharge Current(A) |
70 |
90 |
120 |
125 |
190 |
210 |
| Lithium Battery Comm. |
Optional self-adapting BMS |
| Number of Battery Inputs |
1 |
| PV Input Parameters |
| Max.DC access Power(W) |
6000 |
7200 |
10000 |
12000 |
16000 |
20000 |
| Max.DC Input Power (W) |
6000 |
7200 |
10000 |
12000 |
12800 |
16000 |
| Max.DC Input Voltage(V) |
500 |
| MPPT Voltage Range(V) |
150~425 |
| Startup Voltage (V) |
125 |
| Rated PVInput Voltage(V) |
370 |
| Max. Operating PV input Current(A) |
20 |
20/20 |
26/26 |
| Max.Input Current (A) |
25 |
25/25 |
34/34 |
| Number of MPPT Trackers |
1 |
211+1 |
2/2+2 |
2/2+2 |
| AC Input/Output Parameters |
| Rated AC Power(VA) |
3000 |
3600 |
5000 |
6000 |
8000 |
10000 |
| Max.AC Power(VA) |
3300 |
3960 |
5500 |
6600 |
8800 |
11000 |
| Peak Power(Surge) |
>200%,15sec |
>200%,10sec |
| Rated AC Input/Output Current (A) |
13.7/13.1 |
16.4/15.7 |
22.8/21.8 |
27.3/26.1 |
36.4/34.8 |
45.5/43.5 |
| Max.AC Input/Output Current (A) |
15/14.4 |
18/17.3 |
25/24 |
30/28.7 |
40/38.3 |
50/47.9 |
| Max.AC Input Curent(BP)(A) |
35 |
35 |
35 |
40 |
50 |
50 |
| Rated Input/Output Voltage Range |
220V/230V 0.85Un-1.1Un |
| Grid Connection Type |
L+N+PE |
| Rated Input/Output Freq./Range |
50Hz145Hz~55Hz 60Hz/55Hz~65Hz |
| Output Power Factor |
1(0.8 leading～0.8 lagging) |
| Total Current Harmonic Distortion(THDi) |
<3%(at nominal power) |
| DC Current Injection |
<0.5%In |
| Efficiency |
| Maximum Efficiency |
97.6% |
| Euro Efficiency |
96.5% |
| MPPT Efficiency |
>99% |
| Protection |
| Integrated Protections |
DC Reverse Polarity, AC Output Over-current, Thermal, AC Output Over-voltage, AC Output Short-circuit, DC Injection Monitoring, Arc Fault Circuit Interrupter (Optional), Anti-lslanding, DC Switch, Insulation Impedance Detection, Residual Current Monitoring |
| Surge Protection Type |
Type I(DC), Type II (AC) |
TYPEII(DC),TYPE HI(AC) |
| Communication &Monitoring |
| Communication Interface |
RS485/CAN |
RS485/RS232/CAN |
| Monitoring Options |
GPRS/Wi-Fi/Bluetooth/4G/LAN (Optional) |
| General Parameters |
| Operating Temperature(℃) |
-25～60℃(Derating>45℃) |
-40 to+60℃(Derating>45℃) |
| Storage Temperature(℃) |
-30～65℃ |
45～65℃ |
| Relative Humidity |
0～100% |
| Operating Altitude(m) |
≤2000m |
| Cooling Method |
Natural Cooling |
Intelligent Air Cooling |
| Noise(dB) |
<30 dB |
| Weight(kg) |
13 |
26.8 |
| Dimensions (WHD mm) |
338*480*205 |
580*330*242 |
| IP Rating |
IP66 |
| Topology |
Transformerless |
Non-lsolated |
| Safety &EMC Certification |
IEC62109,IEC61000,IS 16169&IS 16221(BIS) |
| Grid-Tie Certification |
IEC61727,EN50549-1,VDE-4105,NRS-097-2-1,OVE-Richtlinie R25,UNE217001/2,Ordinace No.140 |
| Other Certification |
IEC61683,IEC62116,EN50530,IEC60068 |
English
中文简体
IP66 High level protection
LCD Color Screen Operation
AC couple to retrofit existing solar system
200% PV Input Maximizes Solar Energy Utilization
Max 210A Charge / Discharge Current
Support up to 6 unit in parallel
Single PV Operation Supported
Dual back up output
UPS switch over time < 10ms
