Multi-Fusion
• All-in-One design
• EMS, hybrid inverter and BMS integrated technology
• Support black start function and off-grid operation
• Power supply redundancy design -
Protection
• Smoke and temperature detection
• System active exhaust and fire alarm
• Battery pack and system use aerosol fire suppression -
Flexible
• Supports DC parallel connection of up to 6 units
• AC parallel expansion: max 3 units -
High Efficiency & Convenience
• Ultra-high energy density
• Compact size
• Simple installation & easy transportation -
Reliability
• IP55-rated for outdoor use
• Wide temperature range:-20°C~55°C
| Technical Data | Jupiter HB-S50/100 | Jupiter HB-S60/130 |
| System Specification | ||
| Nominal Output Power /UPS Power(W) | 50000 | 60000 |
| AC Output Frequency and Voltage | 50/60Hz,230V/400Vac | |
| Grid Type | 3/N/PE | |
| Number of Parallel | DC: Up to 6 units AC: Up to 3 units | |
| Energy Configuration(kwh) | 100.35 | 129.02 |
| Dimension(W×D×H,mm) | 1140×1880×1175 | |
| Weight Appr. (kg) | 1744 | 1956 |
| AC Output Rated Current(A) | 83.4A | 100A |
| Battery Operating Voltage(V) | 313.6~403.2 | 403.2~518.4 |
| MaX.RTE | 93% | |
| Battery Chemistry | LiFePO₄ | |
| IP Rating of Enclosure | IP55 | |
| Installation Method | Floor-Mounted | |
| Storage Temperature(℃) | 0~35 | |
| Operating Temperature(℃) | -30~60℃ | |
| Warranty | 5 years | |
| Inverter Technical Specification | ||
| Max.PV Input Power(W) | 80000 | 90000 |
| Max.PV Input Current(A) | 4*40A | |
| Rated PV Input Voltage(Vdc) | 600 | |
| Start Up DC Voltage(Vdc) | 180 | |
| MPPTVoltage Range(Vdc) | 180-1000 | |
| MaX.PV Short-Circuit Current(A) | 4*60A | |
| Number of MPPT | 4 | |
| Peak Power(off grid) | 1.5 time of rated power;10s | |
| Power Factor | 0.8 leading to 0.8 lagging | |
| THD | <3% | |
| Display | LCDIAPPMeb | |
| Operating Temperature Range(℃) | -30~60℃ | |
| Relative Humidity | 5~85 | |
| Dimension(W×D×H,mm) | 620×900×300mm | |
| Inverter Communication | RS485/CAN/WFI/4G/LAN/Bluetooth | |
| Grid Regulation | VDE4105, EC61727/62116, VDE0126, AS4777.2, CEI0-21, EN50549-1, G98, G99, C10-11, UNE217002, NBR 16149/NBR 16150 | |
| Max.Efficiency | 98.40% | |
| Battery Technical Specification | ||
| Battery Module Nominal Voltage(V) | 51.2 | |
| Battery Module Energy(kWh) | 14.33 | |
| BMS Communication | CAN2.0/RS485/4G | |
| Battery Module Dimension(W×DxHmm) | 504×781×230 | |
| Battery Module Weight(kg) | 106 | |
| OperatingTemperature Range(℃) | Charge:0~55/Discharge:-20~55 | |
| Cycle Life | >6000(@25℃±2℃,0.5C/0.5C,90%DOD,80%EOL) | |
| Battery Module Certification | UN38.3, SDS, CE, IEC62619 | |
