Scalability
Supports up to 16 units in series, with a total capacity of up to 124 kWh. -
Excellent Low-Temperature Discharge
Performance Capable of discharging at -40°C. -
Easy Installation
Stacking method is adopted for installation. -
Supports multiple communication protocols -
Safer
SIB batteries
Support aerosol fire extinguishing -
8000 cycles @70% for effectively lower total of ownership cost
|
System Parameters |
|||
|
Model |
Jupiter AD54-J1 |
Jupiter AD85-J1 |
Jupiter AD116-J1 |
|
Nominal Voltage(V) |
319.2 |
501.6 |
684 |
|
Battery Module Qty In Series(Optional) |
7 |
11 |
15 |
|
Operating Voltage(V) |
168~392 |
264~616 |
360~840 |
|
Rated Energy(kWh) |
54.26 |
85.27 |
116.28 |
|
Usable Energy(kWh) |
48.82 |
76.74 |
104.65 |
|
Scalability |
7~16 pcs pack+1 pcs HV Box (54~124kWh) |
||
|
Recommended Depth of Discharge(%) |
90 |
||
|
Charge / Discharge Current (A) |
Recommend: 85 Max: 170 |
||
|
Operating Temperature(°C) |
Charge: 0℃~55℃ Discharge: -40℃~55℃ |
||
|
Other Parameters |
|||
|
Storage Temperature(°C) |
-10℃~35℃ |
||
|
Humidity |
5%~95% |
||
|
Altitude |
≤2000m |
||
|
Ingress Protection |
IP20 |
||
|
Cooling Method |
Forced air cooling |
||
|
Installation Method |
Stacking Method |
||
|
Dimension(W×D×H,mm) |
945*815*1151 |
1420*815*1151 |
1895*815*1151 |
|
Approximate Weight(kg) |
890 |
1390 |
1890 |
|
Cycle Life |
≥8000(25℃±2℃,0.5C/0.5C,90%DOD,70%EOL) |
||
|
Battery Pack Parameters |
|||
|
Battery Pack Model |
Jupiter NC7.7-J1 |
||
|
Battery Type |
SIB |
||
|
Battery Pack Nominal Voltage(V) |
45.6 |
||
|
Battery Pack Capacity(Ah) |
170 |
||
|
Battery Pack Approximate Weight(kg) |
110 |
||
|
Battery Pack Dimension(W×D×H,mm) |
795.9×526×275 |
||
|
Warranty Period |
5 years |
||
|
Certification |
UN38.3 |
||
